Basic Info.

Model NO. P5, P6, P8, P10, P16 Pixel Density 40000 Pixels/Sq.M Scanning Mode 1/8 Scan Display Type LED Video Display Application Advertising Certification CE, RoHS, CCC LED Type SMD2727, SMD2525 Transport Package Flight Case, Plywood Case, Carton. Specification CE, ROHS, ISO9001 Trademark BST Origin Shenzhen, China HS Code 8528591090 Production Capacity 3000sqm/Month

Product Description

P5 street light pole Outdoor Full Color Advertising LED display screen

Key Benefits

1. Broad viewing angle;
2. Frame-free installation;
3. Front and rear side maintenance.
4. High brightness, visible even with direct sunshine;
5. High waterproof and dustproof, IP65 both front and rear side
6. Having good lightening accordance and no mosaic;
7. Having large viewing angle: Getting vivid effect within any position of the viewing range;
8. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.

LED DISPLAY, LED STADIUM SCREEN, LED OUTDOOR SCREEN, OUTDOOR BILLBOARD

Model	PH5
Pixel  Pitch	5mm
Unit  Size	1280mm x 1600mm
LED  Type	1R1G1B
Pixel / Unit	256x320
Unit  Weight	120kg(steel) or 90kg(Aluminum)
Viewing  Angle	H140°   V140°
Application	Storage-40~60° C,     Working-20~50° C
Protection  Level	IP65
Power  Consumption	700W/sq.m  Max
	350W/sq.m  Ave.
Driving	1/8
Frame  Refresh	≥60Hz
Data  Refresh  Rate	1200~4000Hz
Processing	16bit
Max    Brightness	6,500-7000nits
Power  Supply	AC90-240V,   50~60Hz
MTBF	≥1000  Hours
Life  Span	≥100000  Hours
Pixel  Failure	< 0.0003
