New Design Shopping Center Transparent LED Display LED Transparent Screen Full Color Indoor LED Video Wall Glass LED Screen
Hefei Yilan Electronics Technology Co., Ltd.Base Info
Description
Product Item Front Light Side/back light P3.91-7.81 P3.91-7.81 Pixel Pitch 3.91mm x 7.81mm 3.91mm x 7.81mm LED Type LED RGB 3in1 RGB 3in1 LED Life LED 100,000 hours 100,000 hours Configuration SMD1921 SMD3010/3510 Module Resolution 128*16 128x16 Pixels Density (dots) 32256/sqm 32256/sqm Brightness (cd/sqm) 700-3500cd/sqm ≥5000 cd/sqm Light Transmittance Rate ≥70% ≥75% Viewing Distance ≥5m ≥5m Viewing Angle 120°/140° 120°/140° Refresh Rate ≥1920HZ ≥1920HZ Gray Scale 16bit. Red, Green and Blue each 16K 16bit. Red, Green and Blue each 16K Color Temperature 3200K-9300K adjustable 3200K-9300K adjustable Scan Mode 1/8 scan 1/8 scan Cabinet Material die-casting aluminum die-casting aluminum Cabinet Size (mm) 500x1000x70 500X1000 Cabinet Weight(kg) 15kg/sqm 15kg/sqm Max Consumption (W/sqm) 500 560 Ave Consumption (W/sqm) 130-180 180 Supply Voltage AC220V/50HZ; AC110V/60HZ AC220V/50HZ;AC110V/60HZ Storage Temperature -20ºC~+60ºC -20ºC~+60ºC Working Temperature -20ºC~+50ºC -20ºC~+50ºC Operating Humidity 10%-80% 10%-80% IP Rating IP20 IP20 Display Capacity Text, Graph and Video Text, Graph and Video Control System LINSN,Nova-star Colorlight (adjustable) LINSN,Nova-star Colorlight (adjustable) Control Mode Synchronous Control Mode Synchronous Control Mode
Features:
Professional transparent led display, light up your window
* High transparency with over 75% transparency rate for front and back. People can
see the video and photos through the glass clearly without any blocking sights.
* Super light, each led panel is around 7.5kg
* Wide Viewing Angle Heat Dissipation
* High Brightness
* It achieves to send video and image by intelligent terminal APP.
Installation:
No need to change any building structure for installation.
Fast maintenance design.
Wide viewing angle
Application:
Widely use for indoor and out door: high protection Rate IP65 waterproof, dustproof, suitable for both indoor and outdoor use. Such as: Business center, hotel, 5A office building, automobile shop, Airport, sightseeing lift, brand store,ect.
About US:
Features:
Professional transparent led display, light up your window
* High transparency with over 75% transparency rate for front and back. People can
see the video and photos through the glass clearly without any blocking sights.
* Super light, each led panel is around 7.5kg
* Wide Viewing Angle Heat Dissipation
* High Brightness
* It achieves to send video and image by intelligent terminal APP.
Installation:
No need to change any building structure for installation.
Fast maintenance design.
Wide viewing angle
Application:
Widely use for indoor and out door: high protection Rate IP65 waterproof, dustproof, suitable for both indoor and outdoor use. Such as: Business center, hotel, 5A office building, automobile shop, Airport, sightseeing lift, brand store,ect.
