Basic Info.

Model NO. Indoor P4-16scan System Operating Platform WIN XP Display Type LED Video Display Application Stage Performance, Advertising, Shopping Guide IP Rating IP43 Certification CE, RoHS, UL, CCC, ETL Transport Package Flight Case Specification 256*128mm Trademark hongking Origin Made in China HS Code 8528591090 Production Capacity 2000000square Meter /Month

Product Description

P4 Full Color LED display screen Billboard for Advertising

Company descripition:
HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress.
Indoor P4 specification details :

Product Model	Indoor Fixed F6	Indoor Fixed F5	Indoor Fixed F4	Indoor Fixed F3	Indoor Fixed F2.5
Pixel Pitch	6mm	5 mm	4 mm	3 mm	2.5mm
Module Size	192x192mm	160x160 mm	256x128 mm	192x192mm	160x160 mm
Module Resolution	32x32 pixels	32x32 pixels	64x32 pixels	64x64 pixels	64x64 pixels
LED	SMD3528	SMD3528	SMD2121	SMD2121	SMD2121
Standard Cabinet Size	960x960 mm	960x960 mm	768x768mm	576x576mm	480x480 mm
Standard Cabinet Resolution	160x160 pixels	192x192 pixels	192x192pixels	192x192pixels	192x192 pixels
Standard Cabinet	Iron	Iron	Iron	Iron	Iron
Physical Density	27777 Pixels/m2	40000 Pixels/m2	62500 Pixels/m2	62500 Pixels/m2	40000 Pixels/m2
White Balance Luminance	≥1500 nits	≥1500 nits	≥1200 nits	≥1200 nits	≥1200 nits
Gray Scale per Color	16384 level	16384 level	16384 level	16384 level	16384 level
Contrast	1000:01:00	1000:01:00	1000:01:00	1000:01:00	1000:01:00
Refresh Frequency	≥960 Hz	≥960Hz	≥960 Hz	≥960 Hz	≥960Hz
Visual Angle(Horizontal/Vertical)	140°/140°	140°/140°	140°/140°	140°/140°	140°/140°
Max Power	600 W/m2	600 W/m2	650 W/m2	650 W/m2	700 W/m2
Average Power	200 W/m2	200 W/m2	220 W/m2	220 W/m2	250 W/m2
Input Voltage(AC)	110 V -240 V	110 V -240 V	110 V -240 V	110 V -240 V	110 V -240 V
Working Environment Temperature	-20ºC~50ºC	-20ºC~50ºC	-20ºC~50ºC	-20ºC~50ºC	-20ºC~50ºC
Operating Humidity	10%RH~95%RH	10%RH~95%RH	10%RH~95%RH	10%RH~95%RH	10%RH~95%RH
Control System	AV,Video,VGA,DVI,HDMI,SDI,DP	AV,Video,VGA,DVI,HDMI,SDI,DP	AV,Video, VGA,DVI,HDMI,SDI,DP	AV,Video,VGA, DVI,HDMI,SDI,DP	AV,Video,VGA,D
