Basic Info.

Model NO. Outdoor P5-8scan Pixel Density 40000dots/M2 Scanning Mode 1/8 Scan Display Type LED Video Display Application Advertising Certification CE, RoHS, UL, CCC Transport Package Wooden Case Specification 960*960mm Trademark hongking Origin Made in China HS Code 8528591090 Production Capacity 2000000square Meter /Month

Product Description

Outdoor P5 led display screen video wall
Why I recommend my customers to choose P5 outdoor Full color LED Display? Please browse four points as follows:

1. High Brightness:

We are a professional factory which specialises in producting Outdoor Full color LED Display and LED Module, The Brightness is at least 7500CD/sq. M;

2. Waterproof:

The Standard Of LED Cabinet is IP65, which it can protect the rain and dust into the screen. You can fixed install the screen in the rainy day.

3. Wide Used in the outdoor:

Widely used in Public, street advertising, shopping mall. Plaza station, Building billboard, expressway, ect.

4. Energy Saving and PRO-Environment:

Such as P5 outdoor Full color LED display, 100sq. M; If it is spent for 14hours/day, total 365 days/year. The Energy Saving LED display will be save over 10, 000 hours than traditional screen each year.


Product Model	Outdoor Fixed F10-2S	Outdoor Fixed F8-4S	Outdoor Fixed F6-8S	Outdoor Fixed F5-8S	Outdoor Fixed F4-8S
Pixel Pitch	10 mm	8 mm	6 mm	5 mm	4 mm
Module Size	320x160 mm	256x128 mm	192x192 mm	160x160 mm	256x128 mm
Module Resolution	32x16 pixels	32x16 pixels	32x32 pixels	32x32 pixels	64x32 pixels
LED	SMD3535	SMD3535	SMD3535 or SMD2727	SMD2727	SMD2525
Standard Cabinet Size	960x960 mm	1024x1024 mm	768x768 mm	960x960 mm	1024x1024 mm
Standard Cabinet Resolution	96x96 pixels	128x128 pixels	128x128 pixels	192x192 pixels	256x256 pixels
Standard Cabinet	Iron	Iron	Iron	Iron	Iron
Physical Density	10000 Pixels/m2	15625 Pixels/m2	27777 Pixels/m2	40000 Pixels/m2	62500 Pixels/m2
White Balance Luminance	≥6500 nits	≥7000 nits	≥6500 nits	≥6000 nits	≥6000 nits
Gray Scale per Color	65536 grades gray(16 bit)	65536 grades gray(16 bit)	65536 grades gray(16 bit)	65536 grades gray(16 bit)	65536 grades gray(16 bit)
Contrast	5000:01:00	5000:01:00	5000:01:00	5000:01:00	5000:01:00
Refresh Frequency	≥1920 Hz	≥1920 Hz	≥1920 Hz	≥1920 Hz	≥1920 Hz
Visual Angle(Horizontal/Vertical)	140°/140°	140°/140°	140°/140°	140°/140°	140°/140°
Max Power	600 W/m2	650 W/m2	900 W/m2	1000 W/m2	1000 W/m2
Average Power	200 W/m2	250 W/m2	300 W/m2	350 W/m2	350 W/m2
Input Voltage(AC)	110 V -240 V	110 V -240 V	110 V -240 V	110 V -240 V	110 V -240 V
Working Environment Temperature	-20ºC~50ºC	-20ºC~50ºC	-20ºC~50ºC	-20ºC~50ºC	-20ºC~50ºC
Operating Humidity	10%RH~95%RH	10%RH~95%RH	10%RH~95%RH	10%RH~95%RH	10%RH~95%RH
Control System	AV,Video,VGA,DVI,HDMI,SDI,DP	AV,Video,VGA,DVI,HDMI,SDI,DP	AV,Video,VGA,DVI,HDMI,SDI,DP	AV,Video,VGA,DVI,HDMI,SDI,DP
