Basic Info.

Model NO. P2.5mm, P4mm, p5mm, P6.67mm, P8mm Pixel Configuration 1R, 1G, 1B Display Function Video Display Average Power Consumption 450W/Sq.M Pixel Density 160000 Pixels/Sq.M Scanning Mode 1/8 Scan Display Type LED Video Display Application Advertising Certification CE, RoHS, CCC Delivery Time 20 Days Refresh Rate >1500Hz LED Type SMD1415 Warranty 2 Years Cabinet Size 960mmx960mm OEM Yes Transport Package Flight Case, Plywood Case, Carton. Specification CE, ROHS, ISO9001 Trademark BST Origin Shenzhen, China HS Code 8528591090 Production Capacity 5000sqm/Month

Packaging & Delivery

Package size per unit product 96.00cm * 96.00cm * 8.00cm Gross weight per unit product 25.000kg

Product Description

P2.5mm SMD1415 Outdoor Full Color Advertising LED Display for Shopping Mall



Key Benefits

1. Broad viewing angle;
2. Frame-free installation;
3. Front and rear side maintenance.
4. High brightness, visible even with direct sunshine;
5. High waterproof and dustproof, IP65 both front and rear side
6. Having good lightening accordance and no mosaic;
7. Having large viewing angle: Getting vivid effect within any position of the viewing range;
8. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.

LED DISPLAY, LED STADIUM SCREEN, LED OUTDOOR SCREEN, OUTDOOR BILLBOARD

Model	PH2.5
Pixel  Pitch	2.5mm
Unit  Size	960mm x 960mm
LED  Type	SMD1415
Pixel / Unit	384x384
Unit  Weight	28kg(Aluminum)
Viewing  Angle	H140°   V140°
Application	Storage-40~60° C,     Working-20~50° C
Protection  Level	IP65
Power  Consumption	600W/sq.m  Max
	300W/sq.m  Ave.
Driving	1/4
Frame  Refresh	≥60Hz
Data  Refresh  Rate	1200~4000Hz
Processing	16bit
Max    Brightness	5,500-6500nits
Power  Supply	AC90-240V,   50~60Hz
MTBF	≥1000  Hours
Life  Span	≥50000  Hours
Pixel  Failure	< 0.0003
