LED Display Series

BST-IRD-2.84

BST-IRD-2.98

    BST-IR-3.91

Pixel Pitch(mm)

2.84

2.98

          3.91

Pixel Density(dots/m²)

123904

112896

        65536

Avr Power Consumption (W/M²)

              ≤500

              ≤500

         ≤500

Brightness Max(cd/m²)

≥800

≥1000

         ≥1000

Color Temperature(after calibration)K

6500

6500

          6500

Cabinet Material

Die Casting Aluminum

Die Casting Aluminum

  Die Casting Aluminum

Weight(kg/Panel⁾

7.5

7.5

             7.5

      Working Humidity

          10%-95%

         10%-95%

        10%-95%

      Driving Method

             1/22

             1/28

          1/16

LED Type

SMD2121

SMD2121

          SMD2121

Horizontal/Vertical Viewing Angle(º)

H140º/V140º

H140º/V140º

        H140º/V140º

Recommended Viewing Distance(m)

1--100

1-100

            1--100

Power Supply

Single power

Single power

        Single power

Refresh Rate(Hz)

≥1920

≥1920

            ≥1920

         Weight(kg/m²)

             28

            28

           28

Grey Scale(bit)

R'G'B 16bit

R'G'B 16bit

           R'G'B 16bit

Frame Rate(Hz)

50/60

50/60

           50/60

Life Time(H)

≥100000

≥100000

            ≥100000

Protection

Indoor

Indoor

            Indoor

Cabinet Size(W*H)(mm)

           500X500

  500X500/ 500X1000

  500X500/ 500X1000

        LED Chip

           Epistar

          Epistar

           Epistar

      Contrast

            4000:1

           4000:1

         2000:1

Protection

IP40

IP40

IP40

Max Power Consumption(W/M²)

800

800

             800

Working Temperature

-20C°/40C°

-20C°/40C°

            -20C°/40C°

Module Size(W*H)(mm)

250X250

250X250

            250X250

        Driving Chip

        MBI5124

       MBI5124

       MBI5124

Control Input

DVI/HDMI/HDSDI

DVI/HDMI/HDSDI

     DVI/HDMI/HDSDI

Max Hanging(Vertical)

≥200kg

≥200kg

            ≥200kg

Why choose BST?

1. BST is a professional manufacturer of LED display screens over 10 years. We have strong R&D to ensure high end products with user-friendly design .
2. The prices are very competitive due to our large-scale procurement of raw material.   We can help you to win more orders if you are distributors.End users will also be satisfied with our quality and price.
3. We have CE, FCC and Rohs certificates. Our products are exported over 85 countries .We have rich experience in handling all possible problems when you import goods from China .
4. We have a wide variety of products for you to choose from .All products are strictly tested before release to market and we test every LED screen 72 hours before delivery.
5. Our sales are well trained to offer professional advice on your specific projects. Processional engineers are on standby, can offer guidance, on site technical support as requested.
6. We offer 2-3 years warranty and life time maintenance .Even when warranty time expires , we only charge material costs
