P4.81 Commercial Rental LED Display Video Wall Screen (HD)
Shenzhen BST Industry Co., LimitedBase Info
Description
Model No.
BST-IRD-4
Pixel Pitch
4.81mm
Module Size
250mm*250mm
Module Resolution (W*H)
52 dots*52 dots
Pixel Density
43264 dots/ sqm
LED Type
SMD2121 LEDs
Pixel Configuration
1R1G1B
Wavelength (R.G.B)
R:625±2nm G:525±2nm B:470±2nm
Drive Mode
Dynamic 1/13 Duty Constant Current
Cabinet Size
500 ×1000 ×70mm
Cabinet Resolution
104dots ×208dots
Brightness
≥ 1200cd/sqm
Contrast
≥ 4000:1
Viewing Angle
140°(Horizontal )/140°(Vertical )
Best Viewing Distance
4m-30m
Grey Scale
16bits/1024levels
Color Capability
16,777,216
Color Temperature
5000-9300K
Maximum Power Consumption
700 W/sqm
Average Power Consumption
300 W/sqm
Working Voltage
AC 220V/110V s±10% 50-60 HZ
Frame Frequency
60-85 HZ
Refresh Frequency
>1500HZ
Brightness Correction
Pixel, Module, Cabinet Correction
Operating Temperature
-40~+60ºC
Operating Humidity
10-90% RH
LED Lifespan
100,000 hours
MTBF
≥50,000 hours
Computer Operation System
Win 98/ Win XP/ Win 2000/Win 7/ Win 8
Video Signal Input
RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite
Video Signal Output
RF, S-Video, RGB, RGBHV, YUV, YC etc.
Graphics Card
DVI Graphics Card
Control Distance
LINSN / NOVA / DB-STAR
Software
LED studio 10.0
Installation
hung and stand
Out of Control Rate
0.01 %
Why choose BST?
- BST is a professional manufacturer of LED display screens over 8 years. We have strong R&D to ensure high end products with user-friendly design .
- The prices are very competitive due to our large-scale procurement of raw material. We can help you to win more orders if you are distributors.End users will also be satisfied with our quality and price.
- We have CE, FCC and Rohs certificates. Our products are exported over 85 countries .We have rich experience in handling all possible problems when you import goods from China .
- We have a wide variety of products for you to choose from .All products are strictly tested before release to market and we test every LED screen 72 hours before delivery.
- Our sales are well trained to offer professional advice on your specific projects. Processional engineers are on standby, can offer guidance, on site technical support as requested.
- We offer 2-3 years warranty and life time maintenance .Even when warranty time expires , we only charge material costs
Many selections:
indoor smd full color led display:p3,p4,p5,p6,p7.62,p8,p10,p12,p16.
outdoor smd full color led display:p6,p8,p10,p12,p16,20.
Our service
1. Your inquiry related to our products or price will be replied in 24 hrs
2. OEM ODM,and your customized lightings we can help you to design and put into product
3. Protection of your sales area,ideas of design and all your private information
4. Top Quality+Reasonable Price+Responsible After Service=Successful & Win
5. Produce all kinds of Pitch: P4.75,P6.0, P7.62, P10, P12, P16, P20, P25, P31.25...,
6. We offer a 1-3 year warranty service according different order, and to provide free technical guidance. We have a professional service team; they are always online waiting to serve you. During the warranty period, all damaged parts could be replaced free of charge.
