Basic Info.

Model NO. indoor p2.976 LED display board System Operating Platform WIN XP Display Type LED Dot Matrix Display Application Stage Performance, Advertising, Shopping Guide IP Rating IP43 Certification CE, RoHS, UL, CCC, ETL Product Name P2.976 LED Display Screen Bightness CD/Sqm 1000CD/Sqm Warranty 3 Years Warranty Driver IC Mbi5124 or Icn 2153 Cabinet Size 500*500mm or 500*1000mm Color Temperature 15000-9500K Transport Package Wooden Case Flight Case and Carton Specification 250*250mm Trademark hongking Origin Shenzhen China HS Code 8528591090 Production Capacity 5000 Sqm/Year

Product Description

Outdoor Indoor LED Display Screen Panel for Advertising



1.Most of our product use material as follow:
    MBI5124IC  Driver IC
    g-energy power supply
    pcb 1.6mm ,mask and base
    2-3 years warranty.

• Contact person : Phebe
• Mobile phone: 00 86 177 2460 2807

 2. If you have interests in buying, pleased send A complete inquiry need to show:
      1. led screen panel pixel pitch, if you dont know how to choose, contact us
      2. led screen size:length ___m; width___m,or cabinet quantity;
      3. use for indoor or outdoor;  fixed installation or rental?
     4. intallation place pictures will be better;





NO.:	Product name	P2.976 LED display screen
1	Pixel Pitch(mm)	2.976mm
2	Pixel configuration	1R1G1B/SMD2020 Black Lamp
3	Pixel density	112896dots/sqm
4	Brightness	≥1000cd/sqm
5	Module size(W*H)	500mm×500mm or 500MMX1000MM
6	Module Resolution (W*H)	84dots x84dots
7	Module weight	600g
8	Cabinet size (W*H)	(500mm×500mm)or(500mmX1000mm)
9	Drive IC	MBI5124 Or MBI5153
10	Drive mode	1/28scan
11	Viewing Angle(V/H)	140 ºC
12	Grey Scale	65536 degree
13	Life time	>100,000 Hours(80%)
14	MTBF	>50,000 Hours
15	Operating Voltage	AC110V/220V±10%
16	Screen Power Consumption	Max: 900w/sqm; Average:300w/sqm
17	Input Power Frequency	50/60Hz
18	Operating temperature	-30--60ºC
19	Humidity	10%-95%
20	Refresh Rate	≥1920HZ
21	Control Method	Synchronized with computer monitor

Our advantages:

1.Price Advantage: we have the best competitive price at the market, also have the same even better quality.Wide viewing angle and the horizontal angle can reach 110 . The images display effect will not Change in the range.
2.Quality advantage: From material to finished product, from design to produce, we control all steps. Good heat dissipation capability because of the unique design of vent fan.High and adjustable LED brightness can meet the demands of the changing requirement of customer in different environments.No mosaic display due to excellent flatness and nice uniformity of light-emitting.
3.Service advantage: Better service at same situation, better cooperation at same service.
4.Certificate:We ensure that our products are the CE certified, ROHS compliant, FCC ,ULidentified and passed the system of ISO 9001
