Seamless Spliciling P4.81 Outdoor Rental LED Screen
Shenzhen BST Industry Co., LimitedBase Info
Description
Basic Info.
Model NO. 4.81mm, 6.25mm Pixel Density 43264pixels/Sqm Scanning Mode 1/5 Scan Display Type LED Video Display Application Stage Performance Certification CE, RoHS Delivery Time 15~25 Working Days Warranty Time 2 Years Cabinet Size 500X1000 OEM Yes Transport Package Flight Case, Plywood Case, Carton. Specification CE, ROHS, ISO9001 Trademark BST Origin Shenzhen, China HS Code 8528591090 Production Capacity 3000sqm/MonthProduct Description
Seamless Spliciling P4.81 Outdoor Rental LED ScreenStage LED Display Screen's Key Feature
1)It is very easy to calculate the size of LED screen.It can be exactly 4*3m, 6m*4m, 8m*5m etc. ( 4m*3m is 4:3 ratio and 8m*4.5m is 16:9 ratio,perfect to show video )
2) Ultra-thin and Super-light: only 7.8KG per cabinet of 500mmW*500mm Hand 12.8 KG per cabinet of 500mm W*1000mm H and depth is only 75mm, can stand on floor independently. 3) 500*1000mm cabinet can work with our 500*500mm die-casting aluminum cabinet so the height of LED screen can be both 1m and 0.5m 4) The appearance is very simple and elegant,looks very high end 5) With specially designed fast lock system, easy to install and dismantle 6) The new structure design enables diversified installation to meet the hanging-up and stacking requirements.
7) .High contrast rate up to 5000:1 by using black LED
8) .High refresh rate with NOVA control system,no scaning line when photographed.
9) . Due to the light weight and low power consumption, it can reduces the labor cost,operating cost and transportation cost
10) 14 bit color,16384 gray scale,showing very clear and vivid video and images.
11) Good thermal design, excellent heat dissipation even no fan installation,
| Model | BST-OR-4.81 |
| Pixel pitch | 4.81mm |
| Pixel density | 43264dots /sqm |
| Module size(W*H) | 250 mm(width)*250 mm(height) |
| Module pixels(W*H) | 52 dots *52 dots |
| Pixel configuration | 1Red 1Green 1Blue |
| Drive mode | constant current driving 1/8 scan |
| LED lamp type | SMD2727 |
| Cabinet size(W*H*D) | 500mm*1000mm/500mmX500mm |
| Color scale | 65,536 degree |
| View angle(H/V) | 140/140 degree |
| Brightness (White balance) | about 6000cd/sqm. |
| Power consumption(one cabinet) | Max:600W / cabinet , Average: 200W / cabinet |
| Operating Voltage | AC110V±10% or 220V ±10%; 50---60HZ |
| Net weight | 12Kg / cabinet |
| Operating temperature | -30°C----+60°C |
| Operating humidity | 10%-95%RH |
| Life time | ≥100,000hours |
| MTBF | 5,000 hours |
| Whole Display Flatness | ≤0.5mm Juncture |
| Frame frequency | 25-60 Hz/s |
| Refresh rate | ≥2000Hz /s |
| Control distance | 100m (without repeater), single mode fiber:20km, multi mode fiber: 500m |
| Power | 110V/220V±15% 47--63Hz |
| LED control system | LINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable |
| Operating system | Windows 2000 / Windows Xp / Windows 7 / windows 8 /8.1 / windows 10 |
| Protections for outdoor display | IP31 |
| Maintenance way | Rear Access |
| Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
