Basic Info.

Model NO. Outdoor P10-2scan Pixel Density 10000dots/M2 Scanning Mode 1/2 Display Type LED Video Display Application Advertising Certification CE, RoHS, CCC, ISO9001 ISO14001 FCC001 ISO14001 FCC Product Name P10 Outdoor LED Display Driver IC Mbi5124 Bightness CD/Sqm 7000CD/M2 Grey Scale 65536 Degree Life Time More 100, 000 Hours (80%) Mtbf More 50, 000 Hours Operating Temperature -30~-60t Humidity 10%-95% Color Temperature 6500K-9500K Warranty 3 Years Transport Package Wooden Case, Flight Case, and Carton Specification 320*160mm Trademark hongking Origin China HS Code 8528591090 Production Capacity 5000 Sqm/Year

Product Description

HD P10 Outdoor Large LED  Display Screen Signage for Advertising
Company descripition:

HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress

• Contact person : Phebe
• Mobile phone: 00 86 177 2460 2807

Product descripition:


NO.:	Product name	P10 high definition rental led display
1	Pixel Pitch(mm)	10mm
2	Pixel configuration	1R1G1B/SMD3535  Black lamp
3	Pixel density	10000dots/sqm
4	Brightness	≥7000cd/sqm
5	Module size(W*H)	320mm×160mm
6	Module Resolution (W*H)	32 dots x 16dots
7	Module weight	400g
8	Cabinet size (W*H)	960mm×960mm
9	Drive IC	MBI5124
10	Drive mode	1/2scan
11	Viewing Angle(V/H)	140  ºC
12	Grey Scale	65536 degree
13	Life time	>100,000 Hours (80%)
14	MTBF	>50,000 Hours
15	Operating Voltage	AC110V/220V±10%
17	Screen Power Consumption	Max: 800w/sqm; Average:270w/sqm
18	Input Power Frequency	50/60Hz
19	Operating temperature	-30--60ºC
20	Humidity	10%-95%
21	Refresh Rate	≥1920HZ
22	Control Method	Synchronized with computer monitor
23	Color Temperature	6500K-9500K
24	LED control system	LINSN,Nova-star,Colorlight is selectable
25	Control Distance	100 m (no repeating); Optical fiber transmission: 500m- 15km
26	Accepting signal with video processor	PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI
27	Systems Operating Platform	Windows Xp / Windows 7 / windows 8 /8.1 / windows 10

Professional production:
Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen




Company descripition:
HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress.

Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies. HONGKINGLED products are approved by CE, CCC, EMC and FC. We are fully certified by ISO standards.



FRQ :

1,Is your LED Display located Indoor, Semi-Outdoor or Outdoor, Mobile or Trailer (required)
 ()Indoor  ()Semi-Outdoor  ()Outdoor  ()Mobile  ()Trailer

2,What is the Length of your LED Display requirement  (required)
(  )Metres


3,What is the Height of your LED display  requirement? (required)
(  )Metres

4,What is the Optimal distance viewing to the LED Display? (required)
(  )Metres


5,What will be displayed on the LED display? (required)
()Text  ()Pictures  ()Videos  ()TV/Camera


6,I will usually program the LED display with the following frequency:
 ()Daily/Weekly & Disconnect  ()Stream Content Continually Online

7,I would like to connect to the LED display using: (required)
 ()Computer Connection control
 ()WiFi Connection control
 ()3G Connection control
