P10 Outdoor Full Color LED Display Screen Sign for Advertising
Shenzhen Hongking Optoelectronic Co., Ltd.Base Info
Description
Technical SpecificationsNO Product name outdoor P10 led display 1 Pixel Pitch(mm) 10mm 2 Pixel configuration 1R1G1B/ 3 Pixel density 10000dots/m2 4 Brightness 6000cd/m2 5 Module size(W*H) 320mm×160mm 6 Module Resolution (W*H) 32dots x 16dots 7 Module weight 450g 8 Cabinet size (W*H) 960mm×960mm 9 Drive IC MBI5124 10 Drive mode 1/4scan 11 Viewing Angle(V/H) 140ºC 12 Grey Scale 65536 degree 13 Life time >100,000 Hours (50%) 14 MTBF >50,000 Hours 15 Operating Voltage AC110V/220V±10% 17 Screen Power Consumption Max: 680w/m2; Average:220w/m2 18 Input Power Frequency 50/60Hz 19 Operating temperature -30--60ºC 20 Humidity 10%-95% 21 Refresh Rate ≥1200HZ 22 Control Method Synchronized with computer monitor 23 Color Temperature 6500K-9500K 24 LED control system LINSN,Nova-star,Colorlight is selectable 25 Control Distance 100 m (no repeating); Optical fiber transmission: 500m- 15km 26 Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI 27 Systems Operating Platform Windows Xp / Windows 7 / windows 8 /8.1 / windows 10
Application
HONGKING LED display screen can be widely used in retail store, pubs and hotels, shopping center, TV and broadcasting center, worship, theater, auto show, award and corporate show, concert touring, rental and staging, festival and sports event, art exhibition, press conference etc.
OEM ODM Service:
Pixels Pitch: P1.6 P1.9 P2 P2.5 P3 P3.91 P4 P4.81 P5 P6 P6.25 P6.66 P7.62 P8 P8.94 P9.64 P10 P12 P13.33 P16 P18.75 P20 P25 P31.25 P37.5mm etc
LED Screen Size: 1x1mts / 2x2mst / 3x2mts / 3x3mets / 4x3mts / 4x4mts / 5x4mts / 6x4mts / 7x5mts / 8x5mts / 10x6mts etc
LED Cabinet Size: 480mmx480mm / 500mmx500mm / 576mmx576mm / 640mmx640mm / 800mmx800mm / 960mmx960mm / 1024mmx1024mm etc
