Model No.

BST-IFS-6-I

Pixel Pitch

6mm

Module Size

192mm×192mm

Module Resolution(Pixel)

32dots×32dots

Pixel Density

27777dots/m2

LED Type

SMD 3 in 1

Pixel Configuration

1R1G1B

Wavelength (R.G.B)

R:625±2nm G:525±2nm B:470±2nm

Drive Mode

Dynamic 1/4 Duty Constant Current

Cabinet Size

1152×2304×150mm

Cabinet Resolution

192dots×384dots

Brightness

≥6000cd/sqm

Contrast

≥2000:1

Viewing Angle

140°(Horizontal )/140°(Vertical )

Minimum Viewing Distance

6m

Grey Scale

16bits/1024levels

Color Capability

16777216

Brightness CorrectionPixel, Module, Cabinet Correction

Color Temperature

5000-9300K

Maximum Power Consumption

1000W/m2

Operating TemperatureStatic:-40°C~+85°C Working:-20°C~+60°C

Average Power consumption

300W/m2

Working Voltage

AC 220V/110V s±10% 50-60 HZ

Frame Frequency

60-85HZ

Refresh Frequency

>1500HZ

Operating Humidity

10-90% RH

LED Lifespan

100,000 hours

MTBF

≥50,000 hours

Computer Operation System

Win 98/ Win XP/ Win 2000/Win 8

Control SystemNetwork controller

Video Signal Input

RF,S-Video,RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite

Control DistanceUTP CAT5E:100m Multi-mode Fiber:500m Single-mode Fiber:10km

Video Signal Output

RF, S-Video, GB, RGBHV, YUV, YC etc.

Graphics Card

DVI Graphics Card

Waterproof Level

IP65 front, IP54 rear

Installation

 stand structure, steel base

Out of Control Rate

0.01 %
