P10 Outdoor full Color LED Screen SpecificationPixel pitch10mmPixel Configuration1R1G1BLED componentDIP346Size of module160mm x 160mmResolution of module16x16dotsSize of cabinet960mmx 960mm Resolution of cabinet96x96dotsMaterial of CabinetIron with back doorsWeight of Cabinet<60KGSBrightness>8000cd/sqmDensity10000dots/sqmBest viewing angle110° /50°Best viewing distance10-150MMaximum power consumption<1000W/sqmAverage power consumption<350W/sqmDriving method1/4 scanControl methodSynchronizationGray scale65536Colors256*256*256Color temperature3200-9300kUniformity97%Working voltageAC220V±10%Working temperature-20ºC~+50ºC±10%Working humidity10% ~ 90%MTBF10,000 hoursFrame frequence50/60HzRefresh frequence>1800HzIP gradeIP65Life Span100,000 hoursData transafer methodRJ45Pratical standardCCC  TUV-CE  ETL etc.Effectivce Communication
Distance(without relay)Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KMAccepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.Systems operating platformWINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
