Basic Info.

Model NO. LM5050-WN30-12V-10MM LEDs Suppliers Honglitronic/Samsung LEDs material packaged by 99.99% pure gold wire LED BINs 3-Step/5-Step, same BIN for each order LED Chip Brand Sanan(Epistar optional) PCB Width 10mm PCB material Double-sided coated pure copper IP Grade IP20/IP60/IP65/IP68 PCB thickness 2Oz (front 35um,back 35um) Adhesive Tape 9495 3000LSE 3M tape Transport Package 5 Meters/Roll with Static-Resistant Bag Specification CE, RoHS, FCC Trademark Leomay Origin Zhongshan, Guangdong, China HS Code 9405409000 Production Capacity 1000 Meters Per Day

Product Description

SMD5050 7.2W/M  30leds/M  12V  Cuttable LED Strips with 3 years Warranty.


Model NO	LM5050-WN30-12V-10MM
Product Name	SMD5050  30LEDS/M  LED strips
PCB Width	10MM
LED Qty/m	30leds/m 5050
PCB Materials	2Oz Double-sided coated pure copper(can print your logo on PCB)
Voltage(V)	12V DC
Rated Power(W)	7.2W/M, 36W/5M
Luminous(lm/m)	840lm/m
LED Chip Brand	Sanan(Epistar optional)
LEDs material	packaged by 99.99% pure gold wire
LED BINs	3-Step/5-Step, same BIN for each order
LEDs Supplier	Honglitronic (Osram/Samsung optional)
CRI(RA>)	CRI80(CRI 90 optional)
Color	W/WW/CW/R/G/B/Y/O/UV/Pink
Color Tempertature	2200K,2700K,3000K,3500K,4000K,6000K,7000K
IP Rate	IP20 (IP54/IP67/IP68 optional)
View Angle	120
Product Size(mm)	10*5000mm
Package(m/rol)	5M/roll(1m/roll,10m/roll,20m/roll.50m/roll,100m/roll. Customized length available)
Working Temperature(ºC)	-20-60
Cutting Unit	3 LEDs
Adhesive Tape	9495 3000LSE 3M tape
Dimmable	Yes
Certificate	UL,CE,Rohs,FCC.
Warranty	3 Years
