• Model NO.：Deyuan Marine
• Certification：CE, CCS
• Weight：4.15 Kg
• Transport Package：Carton Box
• Specification：CCS, CE, GL, MED, EC
• Trademark：Deyuan
• Origin：China
• HS Code：9405409000
• Production Capacity：6000PCS,Month

Basic Info.

Model NO. Deyuan Marine Certification CE, CCS Weight 4.15 Kg Transport Package Carton Box Specification CCS, CE, GL, MED, EC Trademark Deyuan Origin China HS Code 9405409000 Production Capacity 6000PCS/Month

Product Description

Marine Double-Deck Stardboard Light CXH1-101P

 Marine Double-Deck Stardboard Light CXH1-101P:

It refers to the starboard green light and the port red light, each showing uninterrupted light within the horizontal arc of 112.5°. The device shall make the light display from the direct front of the ship to within 22.5° after the right side of their respective sides.For ships less than 20m in length, the side lights can be combined into one and installed on the center line of the ship.

Side light: left red and right green, 22.5 degrees from the front to the rear of each side.The distance from the side light to the side shall not exceed 10% of the ship's width, and the maximum shall not exceed 2m.

Marine Double-Deck Stardboard Light CXH1-101P Features:

Applicable to all kinds of ships of 50 meters or more for night navigation light signal liaison function.

1. The shell is made of high-strength engineering plastic PA+GF, the transparent mask is molded by PC injection molding, and the shading plate

High quality stainless steel molding;

2. No. 1 lamp has an overall sealing structure, which is waterproof when used in harsh environment;

3. The connection between the lamp holder and the base is clamshell type. The bulb can be replaced by unscrewing and turning over the upper cover. More stable than the old plug type;

4, the number of lights used in accordance with the ship's specifications, the average life of no less than 700h;

5. The lamp can work normally in the range of ambient temperature from -30ºC to 55ºC.

Name	Type	Visibility	Level arc	Lamp holder	Bulb	Cable outside Diameter	Protection Class	Color	weight
Double-deck starboard light	CXH2-101P	3n.m	112.5°	P28S	24V/2*60w60cd 110v/2*60w60cd 220v/2*65w60cd	Φ12~Φ13	IP56	Green	4.15 kg
