Basic Info.

Model NO. fox-p4-indoor(SMD) System Operating Platform WIN XP Display Type LED Video Display Application Stage Performance, Advertising, Shopping Guide IP Rating IP60 Certification CE, RoHS, UL, CCC Module Size 128*128mm Best Viewing Distance ≥4m Horizontal Viewing Angle 140° Consumpiton ≤600W/M2 Color Temperature 6500k Driving Method 1/8 Scanning Frame Frequency 60Hz Refresh Frequency 350Hz Life Span >100, 000hours Transport Package Anti-Shaking Wooden Case&Flight Case &Carton Specification CE, RoHS, UL, 3C Trademark FOXGOLDEN Origin Shenzhen, Guangdong, China. HS Code 8528591090 Production Capacity 3000sqm/Month

Product Description

P4 indoor smd 3 in 1 full color led display parameters:

Item	P4
Pixel pitch	4mm
Size of unit board	256mm X 128mm
Resolution of unit board	64 x 32
Density of pixel	62500dots/m2
Pixel configuration	1R1G1B-smd
Red wavelength	625±2nm
Green wavelength	525±2nm
Blue wavelength	470±2nm
Colors	16777216
Best viewing distance	≥4m
Horizontal viewing angle	140°
Maximum power consumption	500W/m2
Brightness	2000-4000 cd /m2
Gray scale	14bits per color
Color temperature	6500k
Control method	Synchronization & Asychronization
Driving method	Constant 1/16 scanning
Frame frequency	60Hz
Refresh frequency	≥180Hz
Working voltage	AC220V/110V±10%
IP grade	Front Ip65/back IP45
Working temperature	-20°C~+80°C
MTBF	10000 hours
Life span	100,000 hours

Our Service
Guaranttee
(1) We guarantee all our displays, modules, parts for two full year. During this time, we will replace or remand our goods for free if there is something wrong with them.
(2) We will provide maintenance  lifetime and charge for the raw materials only.
Technology Training
(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.
 Maintenance and Consultation
(1) We provide  maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consultation by E-mail, call,for free.
 Documents and Certification
 (1) We provide the operation manual, software, test report and so on.
 (2) We can also provide all kinds of certification such as CE, UL and so on.

Trade Terms:

Payment  terms	Prepayment can be negociated -T/T: -Paypal -Western Union -Escrow
Packing	-Standard Export Carton with fully Polyfoam or Pearl Wool -Flight case; -Anti-shaking wooden case
Delivery time	LED module: 1-4  working days after receiving deposit LED display: 5 -15 working days after receiving deposit


Foxgolden profile
FOXGOLDEN GROUP LTD (foxgolden.en.made-in-china.com)is a 11 years professional LED display manufacturer. Since 2004, we have been dedicating to the aim that producing high quality products, and now FOXGOLDEN has been well integrated in terms of R&D, produce, project, capital and marketing,hot sale indoor/outdoor full color led display.



FAQ:
If you want to buy led display,led modules,power supply,control card,etc:
pls contact me,Your inquiry and your questions will be solved in 1hours.
