Standard Caninet Size

Custom

Cabinet Weight

35KGS

Brightness/Adjustment

≥6500cd/m², Level 16- Automatic / Level 100-Manual operation

View Angle

≥120°(Vertical),≥120°(Horizontal)

Best View Distance

6-60m

Grey Scale

Within 65536 Step

Frame Frequency

≥60Hz

Refresh Rate

≥1920Hz

Signal Input Source

Composite, S-video, Component, VGA, DVI, HDMI, SDI, HD-SDI

Scan Mode

1/8Scan

Display Color Qty

16777216

Continuous Working Time

>24(Hrs)

Screen Lifespan

>100,000(Hrs)

MTBF

>5000(Hrs)

Max. power consumption

950W/sqm

Ave. power consumption

320W/sqm

Out of control pixel rate

≥3/10,000(discrete distribution)

Control Distance

100M(Ethernet) 500M(Multi-fiber) 10KM(Sigle-fiber)

Flatness

Screen Surface≤0.5mm,Pixel Pitch≤0.3mm

Operation Temperature

-10ºC~+50ºC

Working Humidity

10%~98%RH

Storage Temperature

-40ºC~+85ºC

Software Connection

Standard Computer Connection,Compatiable With Windows,Unix,Novell

Working Valtage

200~240 V

Temperature Rise

Metal≤40K,Insulation≤65K , After Heat Balance

IP Grade

IP65
