P3 SMD2121 Indoor full Color LED Screen SpecificationPixel pitch2mmPixel Configuration1R1G1BLED componentSMD2121 blackSize of module320mm x 160mmResolution of module160 x 80 dotsSize of cabinet960 mm x 960mm x 150mmResolution of cabinet480 x 480 dotsMaterial of CabinetSteel ironWeight of Cabinet35 KGSBrightness< 1200cd/sq.mDensity250000 dots/sq.mBest viewing angle140° /140°Pixel Configuration1R1G1BBest viewing distance> 2 mMaximum power consumption< 1200W/sqmAverage power consumption< 340W/sqmDriving method1/ 40 scanControl methodSynchronization / Asynchronization (wifi,4G)Gray scale65536Colors256*256*256Color temperature3200-9300kUniformity97%Working voltageAC220V/110V±10%Working temperature-20ºC~+50ºC±10%Working humidity10% ~ 90%MTBF10,000 hoursFrame frequence50/60HzRefresh frequence>1920HzIP gradeIP31Life Span100,000 hoursData transafer methodRJ45Pratical standardCCC  TUV-CE  ETL etc.Effectivce Communication
Distance(without relay)Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KMAccepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.Systems operating platformWINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
