Light Weight P3.91 Outdoor Rental LED Display with Nationstar LEDs
Shenzhen Bako Vision Technology Co., Ltd.Base Info
Description
Panel Dimensions (mm)500 × 500 × 80 500 × 1000 × 80 NO .of Modules Per Panel (W × H) 2 × 2 Physical Resolution of Module (W × H) 64×64/64×128 Physical Resolution of Panel (W × H) 128×128/128×256 Panel Material Die-Casting Aluminum Single Cabinet Weight 9/ 15 kg/panel Gray Scale 14-16 bit Colors 281 trillion Contrast Ratio 4,000: 1 Average Power Consumption 75 /150 W/m² Max Power Consumption 225 /550 W/m² Operating Temp/Humidity -20ºC - 60ºC / 10% - 60% Storage Temp/Humidity -30ºC - 60ºC / 10% - 60% Refresh Rate >1,920 Hz Brightness >5000 nits Horizontal Viewing Angle 160° Vertical Viewing angle 140° Expected Lifetime 100, 000 Hrs Max Stacking 10-20pcs Max Hanging 10-20pcs Servicing Front / Rear IP Rating (Front/Rear) IP 65/ IP 54 Scan Method 1/16 Scan
Case
Project Accomplished: Nov 2017
Location: Russia
Screen Dimension: 46m²
Product Model: BOR-6, pixel pitch 6.25mm
