odel No.

BST-OFS-6

Pixel Pitch

6mm

Module Size

192mm*192mm

Module Resolution(pixels)

32*32

Pael Size

1152mm×2304mm

Panel Resolution(pixels)

192X384

Pixel Configuration(RGB)

SMD2727

Pixel Density(pixels/m2)

27777

Brightness(cdm2)

>6500

Best Viewing Distance(m)

6-100

Max.Power Consumption(W/m2)

>1000

Waterproof Level

IP65

Wavelength

R 620-625 G 520-525 B 470-475

LED SPEC

2727

Viewing Angle

140°(H)/140°(V)

Operating Tempreture

-20~50°C

Video Frame Rate(Hz)

≥60HZ

Display Refresh Rate(Hz)

≥1500HZ

Grey Level(colors)

16.7million

MTBF

≥50000 hours

Lifespan

≥100000Hours

Working Voltage

220V±10% OR 110V±10%

Drive Mode

Constant 1/4

Graphics Card

DVI Graphics card

Video Signal

RF, S-Video, RGB, RGBHV, YUV, YC, etc.

Control System

LINSN

Software

LED studio 10.0

Installation

Wall mount, and stand structure
