P3.91 Indoor LED Display Screen Billboard for Advertising
Shenzhen Hongking Optoelectronic Co., Ltd.Base Info
Description
Basic Info.
Model NO. led display p3.91-16s System Operating Platform WIN2000 Display Type LED Video Display Application Stage Performance, Advertising, Shopping Guide IP Rating IP43 Certification CE, RoHS, UL, CCC, ETL, ISO9001 Product Name P3.91 Driver IC Mbi5124 Bightness CD/Sqm 1300 Grey Scale 65536 Degree Life Time More 100, 000 Hours (50%) Mtbf More 50, 000 Hours Operating Temperature -30~-60t Refresh Rate 1920Hz Color Temperature 6500K-9500K HD 1920Hz Transport Package Wooden Case Flight Case and Carton Specification 500x1000mm Trademark HONGKING Origin Shenzhen China HS Code 8528591090 Production Capacity 1000sqm/ MonthProduct Description
P3.91 Indoor LED Display Screen Billboard for Advertising- Contact person : Phebe
- Mobile phone: 00 86 177 2460 2807
Product descripition:
| NO.: | Product name | P3.91 high definition rental led display |
| 1 | Pixel Pitch(mm) | 3mm |
| 2 | Pixel configuration | 1R1G1B/SMD2121 Black lamp |
| 3 | Pixel density | 65536 dots/m2 |
| 4 | Brightness | 1200cd/m2 |
| 5 | Module size(W*H) | 250*250mm |
| 6 | Module Resolution (W*H) | 64 dots x 64 dots |
| 7 | Module weight | 600g |
| 8 | Cabinet size (W*H) | (500mm×500mm) |
| 9 | Drive IC | MBI5124 |
| 10 | Drive mode | 1/32 scan |
| 11 | Viewing Angle(V/H) | 140 ºC |
| 12 | Grey Scale | 65536 degree |
| 13 | Life time | >100,000 Hours (50%) |
| 14 | MTBF | >50,000 Hours |
| 15 | Operating Voltage | AC110V/220V±10% |
| 17 | Screen Power Consumption | Max: 900w/m2; Average:300w/m2 |
| 18 | Input Power Frequency | 50/60Hz |
| 19 | Operating temperature | -30--60ºC |
| 20 | Humidity | 10%-95% |
| 21 | Refresh Rate | ≥1920HZ |
| 22 | Control Method | Synchronized with computer monitor |
| 23 | Color Temperature | 6500K-9500K |
| 24 | LED control system | LINSN,Nova-star,Colorlight is selectable |
| 25 | Control Distance | 100 m (no repeating); Optical fiber transmission: 500m- 15km |
| 26 | Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
| 27 | Systems Operating Platform | Windows Xp / Windows 7 / windows 8 /8.1 / windows 10 |
HONGKING LED display screen can be widely used in retail store, pubs and hotels, shopping center, TV and broadcasting center, worship, theater, auto show, award and corporate show, concert touring, rental and staging, festival and sports event, art exhibition, press conference etc.
OEM ODM Service:
Pixels Pitch: P1.6 P1.9 P2 P2.5 P3 P3.91 P4 P4.81 P5 P6 P6.25 P6.66 P7.62 P8 P8.94 P9.64 P10 P12 P13.33 P16 P18.75 P20 P25 P31.25 P37.5mm etc
LED Screen Size: 1x1mts / 2x2mst / 3x2mts / 3x3mets / 4x3mts / 4x4mts / 5x4mts / 6x4mts / 7x5mts / 8x5mts / 10x6mts etc
LED Cabinet Size: 480mmx480mm / 500mmx500mm / 576mmx576mm / 640mmx640mm / 800mmx800mm / 960mmx960mm / 1024mmx1024mm etc
