| Model No. | BST-OFS-6 |
| Pixel Pitch | 6.67mm |
| Module Size | 320mm × 320mm |
| Module Resolution(dots) | 48*48 |
| Panel Size | 960mm × 960mm |
| Panel Resolution(dots) | 144 × 144 |
| Pixel Configuration(RGB) | SMD3535 1R1G1B |
| Pixel Density(dots/m2) | 22474 |
| Brightness(cd/m2) | ≥ 6000 |
| Best Viewing Distance(m) | >6m |
| Max. Power Consumption(W/m2) | 1000 |
| Drive Mode | 1/4 scan constant |
| Wavelength | R 620-625 G 520-525 B 470-475 |
| Viewing Angle | 140°(H)/140°(V) |
| Operating Temperature | -20~60°C |
| Video Frame Rate(Hz) | ≥60HZ |
| Display Refresh Rate(Hz) | ≥1600HZ |
| Grey Level(colors) | 16.7million |
| Lifespan | ≥100,000 hours |
| Working Voltage | 220V±15% OR 110V±15% |
| Video Signal Input | RF,S-Video, RGB,RGBHV,YUV,YC,COMPOSITION |
| Control System | LINSN OR Nova |
