PH5.95mm LED Display System(CE,ROHS)Technicial ParametersLED ChipNo.LED constitutionTypes 1SMD3535King lightModule Specifications1Pixel Pitch5.95mm2Module Pixles28246dots3Module Resolution42dots × 42dots              4Module Size250mm × 250mm5Module Weight0.53kg/pcCabinet Specification1Cabinet Size(L × H ×W)500*1000mm ×60mm 2Cabinet Resolution168dots x168dots3Module Quanity8pcs4Pixel Density28246dots/m25Materialdie-casting aluminum 6Cabinet Weight11.5 KGScreen Parameters1Screen AreaW: 1m × H:1m =1  2Cabinet Quantity2 pcs3Modules QuantityW: 4 × H:4 =16pcs4Screen Resolution1778112 dots5Brightness≥6000-7500cd/6Driving Method1/7scan7View AngleHorizontal 140° Vertical 120°8Min. Viewing Distance≥5 meter9Gray scale6553610Colors16384 Billion11Refresh rate≥960Hz12Input VoltageAC220V/50Hz or AC110V/60Hz13Input power 760 W/m2   14Power Consumption (Max. / Ave.)Max: 600 W/m2    Ave : 200 W/m2 15Screen weight35kg/    16MTBF>10,000 hours17Life span≥100,000 hours18IP rating(Front/Rear)F: IP54   /  R : IP5419Temperature-operating-10ºC~60ºC 20Contrast 1000 ; 121Humidity-operating10%~90%22Power SupplyChuanglian23ICMBI512424Controlling systemNovastar25Source compatibility(with video processor)AV,DVI,HDMI,SDI,S-Video,DPetc.Effect Show



Packaging&shipping
