The technology parameter  of P 10outdoorNumberItemP101Pixel pitch10mm 2Size of  modual160mm X 160 mm 3Resolution of modual16*164Density of pixel10000dots/m25Pixel configuration1R1G1B6Red wavelength625± 2nm7Green wavelength525± 2nm8Blue wavelength470± 2nm9Colors1677721610Best viewing distance8-150m11Horizontal viewing angle120°12Maximum power consumption≤ 800W/m 213Brightness≥ 7000cd /m 214Gray scale16bits per color15Color temperature6500k16Control methodSynchronization & Asynchronization17Driving method  constant scanning18Frame frequency60Hz19Refresh frequency≥ 300Hz20Working voltageAC220V/110V± 10%21IP gradeIP6522Working temperature-20° C~80° C23MTBF> 10000 hours24Life span> 100, 000 hours25Defects rate.≤ 0.00001(Led display line standard< 0.0001)26Computer operation system  Win XP/Vista/  Win 2000/WIN7ect.27Video signalRF, S-Video, RGB, RGBHV, YUV, YC. ect





1. Dust-proof: High-temperature spray technology: can greatly increase the capability of rust-proof.

2. Moudle planeness: ≤ ± 0.2mm

3. Super uniformity in color.

4. Long life-span. Use wave soldering technology for circuit board, prevent from humidity and oxidation, can extend its use life.

5...Energy-saving. Use high efficiency switching power supply, reduce failure rate of power supply.

6. Silicagel is filled and embedded on the front face of the display module, and the all-door structural design protects the LED display from water, dust, and corrosion, antifreeze.

7. Passed IP67 waterproof and dustproof test.

8. High reliability. Flexible to work under different climate condition, can work normally in all harsh environment, such as strong wind, sandstorm, high temperature, low temperature, dryness, rainstorm, and so on.

Our service:
1. Guarantee
(1) We guarantee all our displays, modules, parts for two full year.
During this time, we will replace or remend our goods for free
if there is something wrong with them.
(2) We will provide maintenance for a lifetime and charge for the raw materils only.
2. Technology Training
(1) We provide the technology training for free,
which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.
3. Maintenance and Consulation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consulation by E-mail, call, MSN or other ways for free.
4. Documents and Certification
(1) We provide the operation manual, software, test report and so on.
(2) We can also provide all kinds of certification such as CE, UL and so on.
5. CAD Drawing and Fixing
(1) We provide CAD drawing on how to fix up the display for free
 and some other expert suggestion.
(2) We will send our engineers to your place if we are expected after our negotiation.
6. Additional service
(1) We provide you the forwarding information,and some other information
such as flight box, structure information for your reference for free.


FAQ:
If you want to buy led display,led modules,power supply,control card,etc:
Pls send me a inquiry,pls contact me,Your inquiry and your questions will be solved in 1hours.
-----------------------------------------------

Thank you!
