Technical parameterUnit moduleModule size320*160mmPixel pitch10mmPixel density10000dots/m2Pixel configuration2R1G1BLed specificationΦ 5ellipsePixel resolutionW: 16dots*H: 16dotsCabinetDimension960mm*960mm*150mmQuantities of module36pcsPower supply4pcsThermal dischargeFan*2pcsTotal weight55kgBest viewing angle10m-120mTemperatureStorage: -40degree~+80degreeWorking: -20degree~+80degreeThickness15cm can adjustableRemarks: cabinet size can changed, upon project need.PowerWorking voltageAC220V/110V± 10%Average power consumption400WMax. Power consumption≤ 560W/sqmCurrent≤ 20mA(single LED)Control systemCPUPentium4 or aboveOperating systemWIN98/2000/NT/XPControl methodSynchronizationMain technical parameterDriving deviceStatic scanningDrive typeConstant Current driver ICRefresh frequency≥ 400HzGrey scale/colors256 levels of each color(R/G/B)/16.7M colorBrightness of white balanceMore than 8000cd/sqmBrightness adjustment256 levels of each color(R/G/B)by softwareOperating ambient humidity10%--95%Video signalPAL/NTSCControl systemDVI display card+full color controller cardMTBF≥ 10, 000hoursLife span≥ 100, 000hoursFlatnessTolerance of interpixel ≤ 0.3mmTolerance of modules clearance≤ 0.6mmPower switchAutomatic switchDisplay mode1024*768Communication distanceUnshielded twisted pair net line transmission distance 100m, max transmission distance 200m.
Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KMSoftwareLED media playerCertification
