NO.

Parameters

Specifications

1

Model

FS8

2

Pixel Pitch (mm)

8

3

Physical Density (dot/m2)

15625

4

LED Configuration

1R1G1B

5

LED Type

SMD3535

6

Module Size (mm x mm)

256x128

7

Module Resolution (PX x PX)

32x16

8

Drive Mode

1/5 Constant Current Drive

9

Viewing Angle (Deg)

H: 140 / V: 140

10

Brightness (cd/m2)

6000

11

Grey Scale

16bit

12

Refresh Rate (Hz)

1920

13

Cabinet Resolution (PX x PX)

128x96

14

Power Consumption (W/m2)

MAX: 900 / AVE: 300

15

Cabinet Size (mm x mm)

768x768

16

Cabinet Weight (Kg)

28

17

Cabinet Material

Iron/Aluminum

18

Color (M)

>16.7

19

Input Voltage (V)

AC 110V~220V+/-10%

20

Refresh Frame Frequency (Hz)

60

21

Protection Level

IP65

22

Working Temperature (ºC)

-30°- +60°

23

Operation humidity (RH)

10%-95%

24

Certificates

CCC ,CE,RoHS
