Basic Info.

Model NO. P4.81 LED Display Pixel Density 6000dots/M2 Scanning Mode 1/8 Scan Display Type LED Video Display Application Stage Performance Certification CE, RoHS, CCC Product Name Outdoor LED Display P4.81 Driver IC Mbi5124 Bightness CD/Sqm 6000CD/M2 Grey Scale 65536 Degree Life Time More 100,000 Hours (50%) Mtbf More 50,000 Hours Operating Temperature -30~-60t Humidity 10%-95% Color Temperature 6500-9500K Module Weight 550g Transport Package Wooden Case Flight Case and Carton Specification 250*250 mm Trademark hongking Origin Shenzhen China HS Code 8528591090 Production Capacity 5000 Sqm/Year

Product Description

Outdoor P4.8 Stage Rental LED Display Screen Sign for Advertising

1.Most of our product use material as follow:
    MBI5124IC  Driver IC
    g-energy power supply
    pcb 1.2-1.6mm ,mask and base
    2-3 years warranty.

• Contact person : Phebe
• Mobile phone: 00 86 177 2460 2807

 2. If you have interests in buying, pleased send A complete inquiry need to show:
      1. led screen panel pixel pitch, if you dont know how to choose, contact us
      2. led screen size:length ___m; width___m,or cabinet quantity;
      3. use for indoor or outdoor;  fixed installation or rental?
     4. intallation place pictures will be better;





NO.:	Product name	P4.8 led display
1	Pixel Pitch(mm)	4.8mm
2	Pixel configuration	1R1G1B
3	Pixel density	43264dots/m2
4	Brightness	5000cd/m2
5	Module size(W*H)	250mm×250mm
6	Module Resolution (W*H)	52 dots x 52dots
7	Module weight	500g
8	Cabinet size (W*H)	(500mm×500mm)or(500mmx1000mm)
9	Drive IC	MBI5124
10	Drive mode	1/8scan
11	Viewing Angle(V/H)	140 ºC
12	Grey Scale	65536 degree
13	Life time	>100,000 Hours (50%)
14	MTBF	>50,000 Hours
15	Operating Voltage	AC110V/220V±10%
17	Screen Power Consumption	Max: 900w/m2; Average:300w/m2
18	Input Power Frequency	50/60Hz
19	Operating temperature	-30--60ºC
20	Humidity	10%-95%
21	Refresh Rate	≥1920HZ
